Semi-Solid State400Wh/kg Series

SLD4-6S80Ah Semi-Solid Drone Battery

Name: SLD4-6S80Ah | 6S 80Ah Semi-Solid Drone Battery 400Wh/kg
SKU: SLD4-6S-80Ah-L

6S 80Ah semi-solid-state industrial UAV battery with 21.0V nominal voltage and 400Wh/kg cell energy density

80AhCapacity

21.0VNominal voltage

400Wh/kgCell energy density

10CDischarge rate

ISO 9001 certified factory
Voltage, capacity, connector & BMS customizable
Engineer reply within 24 hours

Specifications

Model: SLD4-6S80Ah
Capacity: 80000mAh
Nominal Voltage: 21.0V
Energy: 1680Wh
Cell Energy Density: 400Wh/kg
Configuration: 6S
C-Rate: 10C
Maximum charge current: 80A(1C)
Charge cut-off voltage: 25.8V
Discharge cut-off voltage: 15.0V@T>=0C 13.2V@T<0C
Continuous discharge rate: 240A(3C)
Maximum discharge current: 800A(10C)@10S(SOC>50%)
Cycle life: 500 cycle
Working temperature: -40~55C
Storage temperature: -20~40C
Storage humidity: <85%RH
Dimensions: 75*117*350mm
Weight: approx. 4.4kg
Power plug: QS8(Optional)
Balance plug: XH-7P(B0~B6)(Optional)

Product Overview

SOARLID SLD4-6S80Ah Semi-solid-state Battery for industrial UAV applications.

See the full range of 400Wh/kg Semi-Solid-State Drone Batteries, or read how CGBT builds custom semi-solid drone battery packs.

Need a different voltage, capacity or connector?

Every CGBT pack can be built to your airframe: cell configuration, capacity, discharge rate, connectors, enclosure and BMS communication protocol. Send us the model you are looking at and an engineer replies within 24 hours.
