Semi-Solid State350Wh/kg Series

SLD3-14S-105Ah Semi-Solid Drone Battery

14S 51.8V 105Ah semi-solid-state industrial UAV battery, 350Wh/kg cell energy density, 1C/5C discharge.

105AhCapacity
51.8VNominal voltage
350Wh/kgCell energy density
1C/5CDischarge rate
  • ISO 9001 certified factory
  • Voltage, capacity, connector & BMS customizable
  • Engineer reply within 24 hours

Specifications

Model
SLD3-14S-105Ah
Configuration
14S
Nominal Voltage
51.8V
Capacity
105Ah
Energy
5439Wh
Cell energy density
350Wh/kg
C-Rate
1C/5C
Dimensions
175*123*420mm
Cell Energy Density
350Wh/kg
Weight
15.6 kg

Product Overview

The SLD3-14S-105Ah is a 14S 51.8V 105Ah semi-solid-state industrial UAV battery from CGBT, built on 350Wh/kg semi-solid-state cells. It stores approximately 5439Wh of energy and is designed for heavy-lift transport, logistics and long-endurance industrial drones.

Dimensions, connectors, case design and BMS communication protocol can be customized to your airframe. Contact CGBT for the datasheet, sample lead time and OEM pricing.

Need a different voltage, capacity or connector?

Every CGBT pack can be built to your airframe: cell configuration, capacity, discharge rate, connectors, enclosure and BMS communication protocol. Send us the model you are looking at and an engineer replies within 24 hours.
